Lotus EOL - 6" Square Regressed 1st Gen Plenum LED 18W | LL6SRG
Regular price
$60.00
Shipping, returns & support
- ShippingFree standard shipping in Canada over $250.00 CAD. See shipping info.
- Returns30-day returns. See return policy.
- WarrantyNeed warranty or support details? Start with product support.
- SupportTalk to our Calgary-based team through contact & support.
Quick product facts
Quick summary
Overview
The Lotus LED 6-inch square regressed plenum fixture is a contractor-grade recessed lighting solution engineered for architectural precision. Featuring a 2 1/4-inch thin profile, this high-performance luminai...
Technical profile
- Voltage120V
- Wattage18
- Light temperature2700K
- Dimming / controlTriac Dimmable
- Lumens1,000
- CRI90
Key specifications
| Voltage | 120V |
|---|---|
| Wattage | 18 |
| Light temperature | 2700K |
| Dimming / control | Triac Dimmable |
| Lumens | 1,000 |
| CRI | 90 |
| Environment | Wet Location |
| Housing ratings | ["IC Rated", "Air Tight"] |
| Mount type | Recessed Mount |
| Shape | Square |
| Size | 6 |
| Component type | Recessed Downlight |
Product identifiers
- VendorLotus LED Lights
- SKULL6SRG-27K-WH
- MPNLL6SRG-27K-WH
- GTIN'648044943435
- Barcode648044943435
Love this product? Share the transformation and inspire others to upgrade their homes or businesses too!
Overview
The Lotus LED 6-inch square regressed plenum fixture is a contractor-grade recessed lighting solution engineered for architectural precision. Featuring a 2 1/4-inch thin profile, this high-performance luminaire is specifically designed to fit into tight ceiling spaces while providing low-glare, high-quality illumination.
Key Features
- Open Plenum Rated: Architectural-spec construction suitable for commercial installations with open plenum requirements.
- Architectural Design: Deep regressed optics provide high-quality light with significantly reduced glare.
- IC Rated: Approved for direct contact with insulation, eliminating the need for bulky recessed housings.
- High Color Rendering: Features a CRI of 93 for true and vibrant color rendering in demanding environments.
- Extreme Weather Durability: Rated for wet locations and operational in temperatures as low as -40°F (-40°C).
Technical Specifications
- Power: 18W
- Halogen Equivalent: 100W
- Light Output: 1000 lm (2700K) to 1050 lm (4100K)
- Color Temperature: Available in 2700K, 3000K, and 4100K
- CRI: 93
- Beam Angle: 95°
- Input Voltage: 120V AC 50/60 Hz
- Dimming: TRIAC Dimmers 5% - 100%
- Dimensions: ID 6", OD 7", Thickness 2 1/4"
- Cut Out: 6" to 6 1/4"
- Ambient Temperature: -40°F (-40°C) to +104°F (+40°C)
- Projected Life: 70% light output at 50,000 hours
- Certifications: cULus, T24, Energy Star
- Warranty: 10 Year Residential / 5 Year Commercial
