Lotus 3" Bullet Floating Gimbal LED 14W | AD-3-S14W-AR
Regular price
$84.99
Shipping, returns & support
- ShippingFree standard shipping in Canada over $200.00 CAD. See shipping info.
- Returns30-day returns. See return policy.
- WarrantyNeed warranty or support details? Start with product support.
- SupportTalk to our Calgary-based team through contact & support.
Quick product facts
Quick summary
Overview
The Lotus LED 3-inch Bullet Floating Gimbal is an architectural-spec mono-point luminaire designed to provide a track light effect without the need for visible tracks. This multi-directional fixture is highly...
Technical profile
- Voltage120V-347V
- Wattage14
- Light temperature5CCT
- Dimming / controlTriac Dimmable, 0-10V
- Lumens1,000
- CRI90
Key specifications
| Voltage | 120V-347V |
|---|---|
| Wattage | 14 |
| Light temperature | 5CCT |
| Dimming / control | Triac Dimmable, 0-10V |
| Lumens | 1,000 |
| CRI | 90 |
| Beam angle | 24 |
| Environment | Wet Location |
| Housing ratings | ["IC Rated", "Air Tight"] |
| Mount type | Recessed Mount |
| Shape | Bullet / Spotlight |
| Size | 3 |
| Component type | Recessed Downlight |
| Product family | Gimbal |
Product identifiers
- VendorLotus LED Lights
- SKUAD-3-S14W-AR-5CCT-BK-24D
- MPNAD-3-S14W-AR-5CCT-BK-24D
- GTIN'769152014036
- Barcode769152014036
- Product familyGimbal
Love this product? Share the transformation and inspire others to upgrade their homes or businesses too!
Overview
The Lotus LED 3-inch Bullet Floating Gimbal is an architectural-spec mono-point luminaire designed to provide a track light effect without the need for visible tracks. This multi-directional fixture is highly versatile, serving as either a straight downlight or an adjustable accent light for sloped ceilings, wall washing, and highlighting artwork.
+4Key Features
- Multi-Directional Adjustability: Features a floating gimbal design that allows for up to a 30° tilt to precisely direct light where needed.
- 5CCT Switchable: Equipped with a field-selectable color temperature system, allowing users to choose between 2700K, 3000K, 3500K, 4000K, and 5000K.
- IC Rated & Air-Tight: Contractor-grade construction approved for direct contact with insulation and certified air-tight for maximum energy efficiency.
- Integrated Driver: Includes a driver inside the connection box, eliminating the need for a separate junction box and simplifying installation.
- Architectural Optics: Offers a choice of 24° or 38° beam angles and a CRI 90+ rating for high-quality, true color rendering.
Technical Specifications
- Power: 15W
- Light Output (38° Beam): 1095 lm – 1347 lm
- Light Output (24° Beam): 1091 lm – 1365 lm
- Color Temperature: 5CCT Selectable (2700K, 3000K, 3500K, 4000K, 5000K)
- CRI: 90+
- Beam Angle: 24° or 38°
- Tilt Angle: 30°
- Input Voltage: 120V AC (Standard TRIAC Dimmable) / 120-347V AC (Optional 0-10V)
- Dimensions: OD 3 3/16", ID 2 7/8", Length 3 3/4"
- Ambient Temperature: -4°F (-20°C) to +104°F (+40°C)
- Approved Location: Wet Locations
- Projected Life: 70% light output at 50,000 hours
- Certifications: cETLus
- Warranty: 3 Year
